Description
Rotary Drills
MD6380
Pull-Down Capacity
Up to 49 895 kg (110,000 lb)
Hole Diameter
251-381 mm (9.875-15 in)
Engine
Cat® 3512C
SPECIFICATIONS
Designed for large bore hole production drilling in very hard rock, the ultra-class Cat® MD6380 provides the optimal mix of on-board air, feed force, rotary torque and machine mobility. It’s a powerful, rugged machine that can stand up to the conditions of any site and deliver reliable performance with high availability. Robust structures and mast with an integral a-frame allow it to stand up to the toughest conditions, so it delivers long life and reliable performance. With a next-generation cab and operator station, the MD6380 is designed to keep operators comfortable and productive all shift long. Designed to drill holes from 251-381 mm (9.875-15 in) in diameter, the MD6380 is is optimized for single-pass or multi-pass drilling in both rotary and down-the-hole drilling modes.
Specifications
Pull-Down Capacity
Up to 49 895 kg (110,000 lb)
Hole Diameter
251-381 mm (9.875-15 in)
Engine
Cat® 3512C
Bit Load
Up to 53 845 kg (118,719 lb)
Features
Functional in ambient temperature of 52° C (125° F)
Climate Level 1 Standard Fluids and Lubricants (1)
– Temperature range of –1° C (30° F) to 52° C (125° F)
Climate Level 2 Arctic Fluids and Lubricants
– Temperatures down to –18° C (–0.4° F)
Components (1)
Two (2) primary pumps – 280 cc (piston with proportional electronic controls)
Components (2)
One (1) auxiliary circuit pump – 145 cc (piston, load sensing)
Components (3)
Two (2) fan pumps – 100 cc (piston with proportional electronic controls)
Components (4)
Two (2) charge pumps – 74 cc (fixed displacement)
Power Rating (ISO 14396)
949 kW
Emissions (1)
U.S. EPA Tier 2/EU Stage II equivalent
Power Rating (J1995)
960 kW
Engine
Cat® 3512C @ 1,800 rpm
Choice
Rotary, single stage, low pressure 101.9 m³/min (3,600 ft³/min) @ 6.9 bar (100 psi); with low pressure receiver tank for ASME/CRN/AU or CE
Cat 374 EEL - Double Grousers for Hard Rock Applications
750 mm
Cat 374 EEL - Drawbar Pull
980686 N·m
Cat 374 EEL - Double Grousers for Soft Rock Applications
900 mm
Components (5)
Scheduled Oil Sampling (S·O·SSM) ports
Note (1)
Vertical or angle drilling
Hole Diameter Range
251-381 mm (9.875-15 in)
Pull Down Capacity Up To
49895 kg
Bit Load Up To
53845 kg
Rotation Torque Up To
20880 N·m
Single Pass Hole Depth Down To
19.8 m
Multi-Pass Hole Depth Down To
39.5 m
Feature
LH/RH pipe racks hold 9.906 m (32.5 ft) drill pipe
324 mm (12.75 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only
340 mm (13.375 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only
219 mm (8.625 in) diameter
– LH and RH, double pipe rack
– Capable of single and multi-pass
– Primary loader @ 29.68 m (97.4 ft)
– Secondary loader @ 39.59 m (129.9 ft)
273 mm (10.75 in) diameter
– LH and RH, double pipe rack
– Capable of single and multi-pass
– Primary loader @ 29.68 m (97.4 ft)
– Secondary loader @ 39.59 m (129.9 ft)
235 mm (9.25 in) diameter
– LH and RH, double pipe rack
– Capable of single and multi-pass
– Primary loader @ 29.68 m (97.4 ft)
– Secondary loader @ 39.59 m (129.9 ft)
Variable Grip
– 219, 235, 273 mm (8.625, 9.25, 10.75 in)
– 324, 340 mm (12.75, 13.375 in)
One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
– 219 mm (8.625 in)
– 235 mm (9.25 in)
– 273 mm (10.75 in)
– 324 mm (12.75 in)
– 340 mm (13.375 in)
Shock absorber with top sub adapter - available in Standard or Premium
– 219 mm (8.625 in)
– 235 mm (9.25 in)
– 273 mm (10.75 in)
– 324 mm (12.75 in)
– 340 mm (13.375 in)
Cab - Premium
– Includes a leather seat with heat and ventilation, heavy duty suspension, dual pane window glass
– Additional storage plus windshield wipers on front and rear windows
– Removable driller window guard plus front window guard and trainer seat
Cab - Standard
– Includes a fabric seat, single pane window glass, shades, and a windshield wiper for driller window, removable driller window guard and a trainer seat
Service Package - Standard
– Fast fill fuel and water only
– Automated lubricant system
Service Package - Premium
– Service center for lubricant drain and fill
– Fast fill fuel and water
– Automated lubricant system
Water Injection System
2271 l
Water Injection System, High Volume Total Tank Capacity
5299 l
Water Injection System, High Volume Total Tank Capacity (Note 1)
2271 L (600 gal) below deck mounted tank
Water Injection System (Note 1)
Tank below deck
Water Injection/Dry Dust Collection
2271 l
Water Injection System, High Volume Total Tank Capacity (Note 2)
3028 L (800 gal) above deck mounted tank
Water Injection System (Note 2)
Fast fill
Water Injection/Dry Dust Collection (Note 2)
Fast fill
Water Injection/Dry Dust Collection (Note 1)
Tank below deck
Water Injection/Dry Dust Collection (Note 3)
204 m³/min (7,200 ft³/min) dry dust collection
Water Injection System, High Volume Total Tank Capacity (Note 3)
Fast fill
Note (2)
Six (6) each batteries, sealed
– Required for semi/full autonomy packages
Note (1)
Four (4) each batteries, sealed
Components (6)
Product Link™
Components (5)
Electric controls for drilling, tramming, leveling plus auxiliary functions
Height mast up
26.7 m
Height mast down
6.6 m
Length mast down
28.3 m
Note
*Working Length Mast Up with bolt-on platform adds 1.2 m (4 ft) for total of 15.9 m (52.1 ft)
Working Width (non-drill end)
6.06 m
Working Width (drill end)
6.89 m
Mast Only Shipping Length
25.24 m
Working Length Mast Up*
14.7 m
Mast Only
40000 kg
Without Mast
102300 kg
Accessory (1)
Pipe positioner (stabilizer) engaged/disengaged indicator, and interlock
Accessory (2)
One hydraulic pipe catcher
Accessory (3)
Hydraulic pipe support in the upper section of the mast
Type (1)
Radio-ready for communication and entertainment radio
Type (2)
Integrated Terrain for Drilling complete with wiring and harnesses
Components (1)
Single pass auto drill/drill assist
Components (2)
Multi pass auto drill/drill assist
Components (3)
Drill depth meter
Components (4)
Auto level, auto retract jacks, auto raise and lower mast
Working Weight Range
142 300 kg (313,717 lb)
Features
WORLD-CLASS OPERATOR STATION
- Ergonomic controls to help operators stay alert and avoid fatigue
- Multifunction joystick controls and touchscreen monitors are easy to use and intuitive
- Excellent visibility, thanks to multiple cameras and full-length windows
- Optional heated and ventilated seat for enhanced operator comfort
100% CAT INTEGRATION
- Cat to the core, with common parts and components and consistent design characteristics across all Cat drill models
- Shared software for autonomous features
- Backed by the world-class support of the Cat dealer network
CAT ELECTRONICS: BACKBONE OF THE MACHINE
- Common electronic architecture across all Cat machines to ensure technician familiarity
- Cat Electronic Technician (Cat ET) enables fast and easy troubleshooting
- Serves as common platform for integrating future autonomy solutions
- Product Link™ Elite provides real-time performance tracking
MATCHED POWERTRAIN
- Variable air volume for reduced fuel consumption and powerful performance
- C27 engine matched to largest “standard” compressor in this class for fast cycle times
- Powertrain optimized to withstand rigorous drilling applications
- High- and low-pressure configurations offer variable volume air control
- Optimal feed force, rotary torque and air, helping to reduce fuel consumption
TECHNOLOGY AND AUTOMATION
- Integrated Drill Assist functionality, including auto level, auto retract jacks, auto raise and lower mast, and auto drill
- Machine health and performance monitoring keep machine running productively
- Drill depth meter helps reduce over- and under-drilling
- Ready to connect with the Cat MineStar™ suite of technologies, including Terrain for drilling and Command for drilling
SAFETY
- Four standard cameras give the operator excellent visibility: left, right and front view when tramming; carousel view when pipe handling; all three view simultaneously
- Exterior lighting packages have spot and flood lights positioned to illuminate paths for ingress/egress and major service points
- MineStar Command for drilling enables remote or autonomous operation — removing operator from the machine
SUSTAINABILITY
- Designed to use less fuel, which reduces engine emissions
- Reduced waste and lower owning and operating costs thanks to increased commonality of systems and components, plus a reduction in unique part numbers.
- Longer maintenance intervals that decrease the amount of waste contributed to the environment.
CAB
- Premium cab
– Includes a leather seat with heat and ventilation, heavy duty suspension, dual pane window glass
– Additional storage plus windshield wipers on front and rear windows, a removable driller window guard plus front window guard and a trainer seat - Cab roof access system (includes ladders, cage and rails)
- Lights for tram (front and cab)
CONTROLS
- Auto Drill Assist
– Single pass auto drill - Auto Drill Assist
– Multi pass auto drill - Manometer/pressure gauge
- Remote tram
PRODUCT LINK/TERRAIN
- Product Link (Satellite)
- Product Link (Dual)
- Terrain (Guidance)
MAST
- Mast Access Arrangement
– Includes steps, guardrails, landing platforms, and walkway - Drill pipe thread greaser
- Tool Lubrication System
– Rotary tricone, 113.5 L (30 gal) - Flashing beacon for mast clearance
- Overhead winch assembly
– Includes cable and hook plus remote TOP SUB/SHOCK SUB (SELECT ONE)
- 219 mm (8.625 in) premium
- 235 mm (9.25 in) premium
- 273 mm (10.75 in) premium
- 324 mm (12.75 in) premium
- 340 mm (13.375 in) premium
DRILL PIPE – 9.9 M (32.5 FT) LENGTH
- 219 mm (8.625 in) diameter
- 235 mm (9.25 in) diameter
- 273 mm (10.75 in) diameter
- 324 mm (12.75 in) diameter
- 340 mm (13.375 in) diameter
- Pipe thread greaser
TRICONE BITS GROUP (SELECT ONE)
- 9.875 in (251 mm) tricone bit
- 10.625 in (270 mm) tricone bit
- 12.25 in (311 mm) tricone bit
- Bit lock plate 251 mm (9.875 in)
- Bit lock plate 270 mm (10.625 in)
- Bit lock plate 311 mm (12.25 in)
- Bit lock plate 349 mm (13.75 in)
- Bit lock plate 381 mm (15 in)
SERVICE TOOLS
- Lifting bail 152 mm (6 in) BECO for 194‑235 mm (7.625-9.25 in) pipe
- Lifting bail 203 mm (8 in) BECO for 273‑324 mm (10.75-12.75 in) pipe
- Lifting bail 254 mm (10 in) BECO for 340 mm (13.375 in) pipe
- Lifting bail 168 mm (6.625 in) API regular thread for 251-349 mm (9.875‑13.75 in) tricone bit
- Lifting bail 178 mm (7.0 in) API regular thread for 381 mm (15 in) tricone bit
- Bushing retainment tool (8.625-10.75 in pipe) (6 in, 7 in and 7.8 in flats)
- Bushing retainment tool (12.75-13.378 in pipe) (10.5 in and 11.38 in flats)
SERVICE PACKAGES/FLUID SYSTEM
- Premium with Service Center for lubricant drain and fill; automated lubricant system, fast fill fuel and water
CLIMATE/REGIONAL CONSIDERATIONS
- Six (6) batteries (required for autonomy packages)
- Climate Level 2
– Arctic fluids and lubricants
– Temperatures down to –18° C (–0.4° F) FRAME/DECK
- Tool storage box
- Jib crane pedestal only
- Blowdown lines and nozzle (with quick connect cooler end and drill deck)
DUST SUPPRESSION
- Water injection and dust collector
– 2271 L (600 gal) tank below deck
– 204 m³/min (7,200 ft³/min) dry dust collection - High capacity water injection
– 5299 L (1,400 gal)- 2271 L (600 gal) below-deck mounted tank and a 3028 L (800 gal) above deck mounted tank
- Dust curtain hydraulic lifters
– Front and rear dust curtains (recommended with dust collector) - Tram-off Spray System
POWER TRAIN
- Receiver tank for ASME/CRN/AU or CE receiver tank
CAB
- Standard cab
– Includes a fabric seat, single pane window glass, shades, and a windshield wiper for driller window, removable driller window guard and a trainer seat - Viewing hatch to spot over the hole
- LED lighting
CONTROLS
- Basic drill depth indicator and interlocks
PRODUCT LINK/TERRAIN
- Product Link (Cellular)
MAST
- No mast access/handrail only
PIPE LOADER (SELECT ONE)
- 219 mm (8.625 in) diameter
– Two pipe rack
– Capable of single and multi-pass - 235 mm (9.25 in) diameter
– Two pipe rack
– Capable of single and multi-pass - 273 mm (10.75 in) diameter
– Two pipe rack
– Capable of single and multi-pass - 324 mm (12.75 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only - 340 mm (13.375 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only
TOP SUB/SHOCK SUB (SELECT ONE)
- 219 mm (8.625 in) standard
- 235 mm (9.25 in) standard
- 273 mm (10.75 in) standard
- 324 mm (12.75 in) standard
- 340 mm (13.375 in) standard
TOOL GROUPS (SELECT ONE)
- 219 mm (8.625 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal - 235 mm (9.25 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal - 273 mm (10.75 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal - 324 mm (12.75 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal - 340 mm (13.375 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
VARIABLE GRIP HYDRAULIC BREAKOUT WRENCH (SELECT ONE)
- Grip range
– 219, 235, 273 mm (8.625, 9.25, 10.75 in) - Grip range
– 324, 340 mm (12.75, 13.375 in)
DRILL PIPE – 9.9 M (32.5 FT) LENGTH
- No pipe thread greaser
TRICONE BITS GROUP (SELECT ONE)
- Hydraulic bit basket
SERVICE PACKAGES/FLUID SYSTEM
- Standard fast fill for fuel and water only, automated lubricant system
CLIMATE/REGIONAL CONSIDERATIONS
- Air receiver tank low pressure (ASME/CRN/AU) or
- Air receiver tank low pressure (CE)
- Four (4) batteries
- Climate Level 1
– Standard fluids and lubricants
– With a temperature range of –1° C (30° F) to 52° C (125° F) - Certifications CE
FRAME/DECK
- No tool storage box (cover only)
- No jib crane (cover only)
DUST SUPPRESSION
- Water injection only (no dust collector)
– 2271 L (600 gal) tank below deck
UNDERCARRIAGE (SELECT ONE)
- 750 mm (29.5 in) double grousers for hard rock applications or
- 900 mm (35.4 in) double grousers for soft rock applications
Why choose RIMCO Barbados
Reviews
There are no reviews yet.
