Description
Angle Brooms Attachments
BA118C Hydraulic
Used for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
Overall Width
104 in
Sweeping Width
32 in
Brush Diameter
32 in
Specifications
Overall Width
104 in
Sweeping Width
83 in
Brush Diameter
32 in
Required Hydraulics
Standard Flow
Height
36 in
Length
69 in
Weight
955 lb
Optimal Hydraulic Flow
42-86 L/min (11-23 gpm)
Optimal Hydraulic Pressure
145-235 bar (2100-3400 psi)
Motor Displacement
25 in³
Brush Speed at Maximum Flow
199 rpm
Sweeping Width - Angled (± 30 Degrees)
73 in
Overall Width - Angled (± 30 Degrees)
99 in
Drive Method
Direct Drive
Interface Type
Skid Steer Coupler
Optional Hood Extension
40 lb
Features
Application
Ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
Variable Sweeping Angle
Angles hydraulically or manually 30 degrees left or right; will also clean in straight position.
Reliable Hydraulic Motor
Strong gerotor hydraulic motor provides high torque to the bristle core and is designed to maximize performance of standard flow machines. The motor is easily removed using quick release pins for bristle wafer replacement.
Parking Supports
Parking supports provide stable and secure parking of the broom when not in use.
Optional Water Kit
An optional water sprinkler kit is available which helps reduce the amount of airborne dust during your sweeping operations.
Polypropylene and Wire Bristle Options
Cat® Angle Brooms come standard with a 50/50 mix of replaceable polypropylene and steel wire sections. Convoluted bristle sections can be converted to all wire or all poly for special applications.
Why choose RIMCO Barbados
Quality
Exceptional Service
All Emcompassing
Experienced
SUPPORTED EQUIPMENT
259D3 Compact Track Loaders
Gross Power – SAE J1995
55.4 kW
Rated Operating Capacities – 35% Tipping Load
915 kg
Operating Weight
4076 kg
